TYLOK®: SS-GP4-F4F4
Tylok Description: Stainless GP Ball Valve 1/4" FNPT x 1/4" FNPT
Material: 316 Stainless Steel (ASTM A351 Gr. CF8M body)
End Connection 1: 1/4" Female NPT
End Connection 2: 1/4" Female NPT
Cv: 1.20
Pressure Rating: 2,000 psig (138 bar) at 100°F
Temperature Rating: 400°F (204°C) max
Seat Material: TFM 1600
